Cortec Boiler Dragon™

Cortec Boiler Dragon is a highly advanced, ready-to-use liquid designed to protect large boilers and steam systems from corrosion during periods of dry layup, whether it's for a short while or a longer shutdown. It uses special vapor phase corrosion inhibiting (VpCI®) technology to effectively guard metal surfaces.

The magic of Boiler Dragon lies in its unique vapor phase corrosion inhibitors. When applied, these clever molecules transform into a protective vapor that travels throughout all the boiler’s internal spaces. They then settle on all the metal surfaces, even those tricky, hard-to-reach areas, creating a continuous, molecular-level barrier against rust and corrosion.

Absolutely! Cortec Boiler Dragon is formulated for multi-metal protection. This means it's effective on common boiler materials like carbon steel, stainless steel, galvanized steel, cast iron, aluminum, and even copper and its alloys. It's truly a versatile solution for diverse boiler constructions.

Boiler Dragon really steps up the game compared to conventional methods like using desiccants, quicklime, or nitrogen blankets. It's often a safer and significantly more effective alternative because it provides continuous, vapor-phase protection without the hazards or complexities associated with those older techniques. Plus, it simplifies the return-to-service process immensely.

One of the standout benefits of Boiler Dragon is its hassle-free nature. It doesn't form any solid residue, and when it's time to bring your boiler back online, there's no need for product removal or flushing. You simply fill the boiler with makeup water, and you're good to go, saving a considerable amount of time and effort.

Relevant products you may want to consider:

• Cortec VpCI-414 Cleaner/Degreaser
• Cortec VpCI-422 Biodegradable Rust Remover
• Cortec Ecoline Cleaner Degreaser

Boiler Dragon FO is a specific version designed for ferrous metals only. So, if your boiler system primarily consists of iron or steel components and doesn't have significant amounts of other metals like copper or aluminum that require protection, then Boiler Dragon FO might be the more tailored choice. The standard Boiler Dragon offers broader multi-metal protection.

Applying Boiler Dragon is quite straightforward. It's designed to be used as a fogging fluid. You'll typically apply the liquid by spraying or fogging it into the interior of your boiler or steam components. For larger systems, using a low-pressure, high-volume pump or sprayer will make the application efficient.

The general recommendation for Boiler Dragon is to use about 0.7 to 1.0 fluid ounce per cubic foot (or 0.7 to 1.0 liter per cubic meter) of equipment interior. To put it simply, one gallon of Boiler Dragon liquid is typically enough to treat approximately 1,000 gallons (or 1 cubic meter) of boiler volume.

Yes, absolutely! After you've applied Boiler Dragon, it's crucial to seal all boiler openings. This traps the protective vapors inside, allowing them to thoroughly diffuse and form that essential corrosion-inhibiting layer on all metal surfaces, ensuring maximum protection.

That's the beauty of the vapor phase technology! Direct application to every single metal surface isn't necessary. The VpCI® molecules vaporize and then spread throughout the entire enclosed space, reaching even the most inaccessible and recessed areas, providing continuous protection without you needing to manually coat every part.

Relevant products you may want to consider:

• VpCI Vapor Phase Corrosion Inhibitors
• Cortec VpCI Emitters
• Cortec VpCI-337 Corrosion Inhibitor Coating

Yes, Boiler Dragon is incredibly versatile for layup needs. It's specifically designed to provide excellent protection for both short-term preservation periods, like seasonal shutdowns, and for more extended, long-term preservation, even when a boiler might be mothballed.

When dealing with particularly large or intricate systems, a helpful tip is to ensure there's an opening at the opposite end of the boiler from where you're applying the fog. You can fog into one opening until you see the product start to emerge from the other side, then close that opening, finish your dosage, and finally seal the initial opening. Sometimes, a fan or vacuum pump at the opposite end can even help pull the vapors through for complete coverage.

To ensure optimal product performance and longevity, it's best to store Boiler Dragon in its original packaging, indoors, and out of direct sunlight. The ideal storage temperature range is between 40-100 °F (4-38 °C).

Cortec places a strong emphasis on environmentally responsible solutions. Boiler Dragon is formulated without heavy metals, halogens, or solvents. It's also nitrite-free and silicon-free, making it a much safer choice compared to many traditional boiler treatment chemicals.

While it's designed to be safer, it's always wise to exercise caution. It's recommended to wear appropriate personal protective equipment, such as gloves and eye protection, during application. Always refer to the product's Safety Data Sheet (SDS) for detailed safety information and first aid measures.

Relevant products you may want to consider:

• Cortec BioCorr Biodegradable Rust Preventative
• Cortec BioCorr EcoAir Anti-Rust Coating Spray

No, Cortec Boiler Dragon is non-flammable, which adds to its safety profile during storage and application.

You'll be pleased to know that Boiler Dragon has a very low odor, which contributes to a more comfortable working environment during application.

If it comes into contact with your skin, immediately remove contaminated clothing and rinse your skin thoroughly with water. For eye contact, flush your eyes with plenty of water for at least 15 minutes and seek immediate medical attention. If inhaled, move to fresh air. Always consult the product's Safety Data Sheet (SDS) for precise first aid instructions and seek medical advice if irritation persists or symptoms are severe.

When stored correctly in its original packaging, indoors, and away from direct sunlight at the recommended temperatures, Boiler Dragon has a shelf life of 2 years.

Yes, Boiler Dragon is readily water-soluble. This characteristic makes it very convenient to apply and ensures that it won't leave behind any undesirable solid residues that would need to be cleaned out before the boiler is returned to service.

Relevant products you may want to consider:

• Cortec VpCI-377 EcoAir

Boiler Dragon is formulated to be freeze-thaw stable, meaning it can tolerate freezing temperatures and still maintain its effectiveness once thawed, which is a practical benefit for storage in varying conditions.

In its neat form, Boiler Dragon is designed to be pH neutral, typically ranging between 7.1 and 7.5. This neutral pH is important for compatibility with various boiler materials.

The core of its effectiveness lies in its vapor-phase properties. The VpCI® molecules vaporize and then diffuse throughout the entire enclosed boiler system. This allows them to reach and adsorb onto all metal surfaces, including complex geometries, small crevices, and otherwise inaccessible internal components, providing comprehensive protection.

While Boiler Dragon is primarily for dry layup, the protective VpCI layer it forms does not need to be removed. This means the boiler can be filled directly with makeup water, and the transition back to service is very smooth, with no extra steps to worry about. For specific protection during high-oxygen refill, other complementary Cortec products like the Boiler Egg™ are often recommended.

Boiler Dragon is supplied in various convenient sizes to suit different industrial needs, including 5-gallon (19 L) pails, 55-gallon (208 L) drums, larger liquid totes, and even bulk quantities.

Relevant products you may want to consider:

• Cortec Ecoline ELP 19Ltr Pail/Drums
• Cortec CorShield VpCI-369 19Ltr Pail
• Cortec CorShield VpCI-368 19Ltr Outdoor Corrosion Protection Coating
• Cortec BioCorr 19Ltr Biodegradable Rust Preventative

You can directly purchase genuine Cortec Boiler Dragon from Valdamark Direct, who are a reputable distributor for Cortec products in the UK. They can be found via their website.

Boiler Dragon is specifically engineered for larger boilers and steam components. For smaller boilers, Cortec offers other specialized "Boiler Animals" like Boiler Gecko™, which might be more appropriate. Boiler Dragon is chosen for its capacity to protect extensive volumes effectively.

While the product description doesn't explicitly list specific industry certifications for Boiler Dragon, Cortec Corporation as a whole is a global leader in corrosion solutions, with a strong focus on environmentally responsible and effective technologies. They are ISO/IEC 17025 accredited for their corrosion testing lab, indicating a high standard of research and development.

Yes, in many cases, Cortec products are designed to complement each other. For instance, the Boiler Egg™ can be added alongside Boiler Dragon for enhanced protection against oxygen pitting corrosion during the critical startup phase when the boiler is refilled. It's always best to consult with a corrosion expert or refer to Cortec's application guides for integrated solutions.

Valdamark Direct, as an authorized distributor, would be your first point of contact for technical inquiries and support regarding Cortec Boiler Dragon. They often work closely with Cortec's experts to provide comprehensive guidance and ensure you get the most out of your product.
